Team Ferrari 5- Cat Car- Notes



Zoom Feed:

Technical Notes and Sketches:

ESP-32 Robot Car with Dabble Gamepad Control
https://sites.google.com/view/acera-arduino/projects/esp32-robot-car-gamepad

ESP-NOW Projects
https://sites.google.com/view/acera-arduino/iot-projects/esp-now-projects

/***************************************************

 HUSKYLENS An Easy-to-use AI Machine Vision Sensor

https://wiki.dfrobot.com/HUSKYLENS_V1.0_SKU_SEN0305_SEN0336

 <https://www.dfrobot.com/product-1922.html>

/***************************************************

 HUSKYLENS An Easy-to-use AI Machine Vision Sensor

 <https://www.dfrobot.com/product-1922.html>

/***********Notice and Trouble shooting***************

 1.Connection and Diagram can be found here

 <https://wiki.dfrobot.com/HUSKYLENS_V1.0_SKU_SEN0305_SEN0336#target_23>

 2.This code is tested on Arduino Uno, Leonardo, Mega boards.

 ****************************************************/

Sample Program:

#include "HUSKYLENS.h"

#include "SoftwareSerial.h"

HUSKYLENS huskylens;

SoftwareSerial mySerial(10, 11); // RX, TX

//HUSKYLENS green line >> Pin 10; blue line >> Pin 11

void printResult(HUSKYLENSResult result);

void setup() {

    Serial.begin(115200);

    mySerial.begin(9600);

    while (!huskylens.begin(mySerial))

    {

        Serial.println(F("Begin failed!"));

        Serial.println(F("1.Please recheck the \"Protocol Type\" in HUSKYLENS (General Settings>>Protocol Type>>Serial 9600)"));

        Serial.println(F("2.Please recheck the connection."));

        delay(100);

    }

}

void loop() {

    if (!huskylens.request()) Serial.println(F("Fail to request data from HUSKYLENS, recheck the connection!"));

    else if(!huskylens.isLearned()) Serial.println(F("Nothing learned, press learn button on HUSKYLENS to learn one!"));

    else if(!huskylens.available()) Serial.println(F("No block or arrow appears on the screen!"));

    else

    {

        Serial.println(F("###########"));

        while (huskylens.available())

        {

            HUSKYLENSResult result = huskylens.read();

            printResult(result);

        }

    }

}

void printResult(HUSKYLENSResult result){

    if (result.command == COMMAND_RETURN_BLOCK){

        Serial.println(String()+F("Block:xCenter=")+result.xCenter+F(",yCenter=")+result.yCenter+F(",width=")+result.width+F(",height=")+result.height+F(",ID=")+result.ID);

    }

    else if (result.command == COMMAND_RETURN_ARROW){

        Serial.println(String()+F("Arrow:xOrigin=")+result.xOrigin+F(",yOrigin=")+result.yOrigin+F(",xTarget=")+result.xTarget+F(",yTarget=")+result.yTarget+F(",ID=")+result.ID);

    }

    else{

        Serial.println("Object unknown!");

    }

}

-------------------------------------------------------

Clarify control system

#include <Wire.h>

#include <Adafruit_Sensor.h>

#include <Adafruit_BNO055.h>

double xPos = 0, yPos = 0, headingVel = 0;

uint16_t BNO055_SAMPLERATE_DELAY_MS = 10; //how often to read data from the board

uint16_t PRINT_DELAY_MS = 500; // how often to print the data

uint16_t printCount = 0; //counter to avoid printing every 10MS sample

//velocity = accel*dt (dt in seconds)

//position = 0.5*accel*dt^2

double ACCEL_VEL_TRANSITION = (double)(BNO055_SAMPLERATE_DELAY_MS) / 1000.0;

double ACCEL_POS_TRANSITION = 0.5 * ACCEL_VEL_TRANSITION * ACCEL_VEL_TRANSITION;

double DEG_2_RAD = 0.01745329251; //trig functions require radians, BNO055 outputs degrees

// Check I2C device address and correct line below (by default address is 0x29 or 0x28)

// id, address

Adafruit_BNO055 bno = Adafruit_BNO055(55, 0x28);

void setup(void)

{

Serial.begin(115200);

while (!Serial) delay(10); // wait for serial port to open!

if (!bno.begin())

{

Serial.print("No BNO055 detected");

while (1);

}

delay(1000);

}

void loop(void)

{

//

unsigned long tStart = micros();

sensors_event_t orientationData , linearAccelData;

bno.getEvent(&orientationData, Adafruit_BNO055::VECTOR_EULER);

// bno.getEvent(&angVelData, Adafruit_BNO055::VECTOR_GYROSCOPE);

bno.getEvent(&linearAccelData, Adafruit_BNO055::VECTOR_LINEARACCEL);

xPos = xPos + ACCEL_POS_TRANSITION * linearAccelData.acceleration.x;

yPos = yPos + ACCEL_POS_TRANSITION * linearAccelData.acceleration.y;

// velocity of sensor in the direction it's facing

headingVel = ACCEL_VEL_TRANSITION * linearAccelData.acceleration.x / cos(DEG_2_RAD * orientationData.orientation.x);

if (printCount * BNO055_SAMPLERATE_DELAY_MS >= PRINT_DELAY_MS) {

//enough iterations have passed that we can print the latest data

Serial.print("Heading: ");

Serial.println(orientationData.orientation.x);

Serial.print("Position: ");

Serial.print(xPos);

Serial.print(" , ");

Serial.println(yPos);

Serial.print("Speed: ");

Serial.println(headingVel);

Serial.println("-------");

printCount = 0;

}

else {

printCount = printCount + 1;

}

while ((micros() - tStart) < (BNO055_SAMPLERATE_DELAY_MS * 1000))

{

//poll until the next sample is ready

}

}

void printEvent(sensors_event_t* event) {

Serial.println();

Serial.print(event->type);

double x = -1000000, y = -1000000 , z = -1000000; //dumb values, easy to spot problem

if (event->type == SENSOR_TYPE_ACCELEROMETER) {

x = event->acceleration.x;

y = event->acceleration.y;

z = event->acceleration.z;

}

else if (event->type == SENSOR_TYPE_ORIENTATION) {

x = event->orientation.x;

y = event->orientation.y;

z = event->orientation.z;

}

else if (event->type == SENSOR_TYPE_MAGNETIC_FIELD) {

x = event->magnetic.x;

y = event->magnetic.y;

z = event->magnetic.z;

}

else if ((event->type == SENSOR_TYPE_GYROSCOPE) || (event->type == SENSOR_TYPE_ROTATION_VECTOR)) {

x = event->gyro.x;

y = event->gyro.y;

z = event->gyro.z;

}

Serial.print(": x= ");

Serial.print(x);

Serial.print(" | y= ");

Serial.print(y);

Serial.print(" | z= ");

Serial.println(z);

}
